| Technische Daten - Specifications | |
| Wahlen / Selections | 100 - 45 rpm |
| Lampen / Lamps | Select: GE #53 | Cabinet: TL 25 Watt / 28" / T12 | Power supply: GE #309 | Amplifier: #GE 313 |
| Verstärker / Amplifier | 48350-1A |
| Netzteil / Power supply | US: 48445-A | D: 48460-A | B: 48465-A | GB: 48590-A | AUS: 48470-A | Japan: 48450-A |
| Kreditgerät / Credit unit | 50635-A (Std) | 50640-A (US) |
| Lautsprecher / Speaker | 2x 6" 16 Ohm: #50744 | 2x 10" 8 Ohm: #50545 |
| Tonabnehmer / Cartridge | Shure M44R with stylus Shure N44C |
| Sicherungen / Fuses |
Credit Unit: 250mA | Power Supply Germany: 1A, 3A |
Power Supply US: 5A, 3A Amplifier 2x 3A, 2x 240mA |
| Schlüssel / Key | F-592 |
| Abmessungen / Size |
B x H x T: 86 x 112 x 60 cm; 115 kg W x H x D: 44-1/4" x 34-1/8" x 23-1/2"; 230 lbs |
| Zubehör / Accessories |
Aux. Wallbox Power Supply 2121 Wallbox Tri-Vue 507 with stepper 1769 Microphone Kit 2130 Motorized Remote Volume Control (w/o On-Off): 2173 Motorized Remote Volume Control (w. On-Off): 2156-1 Manual Remote Volume Control 2122 L-Pad 2171 | Intermix 2152 | Multi-Pricing Adaptor 2172 Kit 2138 | Microphone Kit 2130 Wallspeaker 1635, 1636 Corner Speaker 1637 Ceiling Speaker 1638 Amplfier Conversion Kit 2174 (mono to stereo) |
| Besonderheiten / Features | Uses old style of selection system by pressing both letter and number buttons, not three digits. |
|
Die Angaben haben keinen
Anspruch auf Vollständigkeit oder Richtigkeit. |
|
