Musikbox Seeburg Jukebox

There had been at least 3 different versions of the Mirrored Teardrop Speaker available:
RS1-12	Remote Speaker for Seeburg 146, 147 & 148 (Trash Can)
RS2-12	Remote Speaker for Seeburg 146, 147 & 148 (Trash Can); with "volume level" switch for adjustments without affecting the volume of the other speakers in the same system - e.g. near a telephone; separate "On-Off-Switch"
CVS2-12	Constant Voltage employed at 70.7 Volt line; colour ivory - starting with model M100A
All models: Output impedance: either 500 Ohm on R.C. Special master Amplifier or 8 Ohm on Master Amplifier
Designer : Arthur William Brockman, patent D147,833 - filed 1946

RS1-12 (1946)

- no photo yet -

RS2-12 (1946)

Pictures: Bill Butterfield
Seeburg Teardrop

Seeburg Teardrop

Arthur William Brockman

Courtesy Gert Almind

Recessed Wall Speaker RS4-8 / RS4-12

- no photo yet -

Recessed Ceiling Speaker RS5-12

Pictures: John
Seeburg Ceiling Speaker RS5-12

Seeburg Ceiling Speaker RS5-12

CVS2-12

- no photo yet -
starting with model M100A
