AMI A

Copyright

78 RPM, 40 selections
Designer: Jean O. Reinecke

AMI A – so called Mother of Plastic (1946-47)

AMI A -Mother of Plastic



AMI Grand Prix – Prototype of AMI A (1946)

Photo courtesy of Ron Seunig
It is said that this prototype was delievered to Belgium for an exhibition and never got back to USA. Another book states that the plastics had been made in Belgium.

AMI A - Mother of Plastic - Grand Prix



Technische Daten - Specifications
Designer Jean Otis Reineke
Wahlen / selections 40
Lampen / lamps

Regarding the lamps used - info Jukebox-List:
"The top left and right are to be red, center above the title pages standard white left and right sides yellow. Bottom of title boards was green.
The bottom had three options as follows, Green Fluorescents only, standard white with fixed color sheets (economy model) Also motorized color cylinders with white bulbs."
Verstärker / amplifier L-20 (silver) - SN: 1-14999: 6SJ7; 6SL7GT, 2x 6L6; 5U4G
BB / R-22 (black) - SN: 15000 and up: 6SJ7; 6SN7GT, 2x 6L6G; 5U4G
Netzteil / power supply
Kreditgerät / credit unit
Lautsprecher / speaker
Mechanismus / mechanism 500
Tonabnehmer / cartridge Astatic 51-2
Sicherungen / fuses
Schlüssel / key 50A-1
Abmessungen (HxBxT) / size
Zubehör / accessories Extra speaker AMIVOX:
stepper: multiwire remote, wallbox iWM 40
Besonderheiten / specialties also called "Mother of Plastic"
