| Technische Daten - Specifications | |
| Wahlen / selections | 48 |
| Lampen / lamps | TL 20 W/24"/T12 |
| Verstärker / amplifier | 510: 5U4G, 2x 6L6G, 6J5, 6SN7GT, 6SJ7 |
| Lautsprecher / speaker | |
| Tonabnehmer / cartridge | Cobra |
| Sicherungen / fuses | |
| Schlüssel / key | RW-44 |
| Gehäuse / cabinet | |
| Abmessungen / size | H x W x D: 151 x 93 x 71 cm / 59-3/8 x 36-1/2 x 27-7/8" | 380 lbs /170 kg |
| Zubehör / accessories | wallboxes
3048,
4820,
4825; stepper
248 resp.
2 x 219;
Kit 113; 3020 + 215
Impulse Transmitter,
Stepper 219 + Imp. Receiver
216 Model 29 Vol. Control for Aux. Amp 227 |
| Besonderheiten / specialties | |
