Seeburg LPC480 (1964-65)
LPC480, LPC480R, LPC480D, LPC480DR
80 Selections, 45 and 33 rpm
Introduced June 1964

Copyright




Frequency versions:

Suffix:


110V 60 Hz: LPC480, LPC480R, LPC480D, LPC480DR
220V 50 Hz: LPC480-H5, LPC480R-H5
220V 50 Hz Export: ELPC480-H5, ELPC480R-H5

R: Remote Control Stepper Unit
T: Tangeringe speaker grille
H5: 220V 50 Hertz

D: Discothèque version
BL: Blue Speaker Grill
XT: no income totalizer


LPC480BL

LPC480T

Seeburg LPC 480
Blue Speaker Grill

Seeburg LPC 480
Tangerine speaker grille







LPC480
Die LPC480 hatte zum einen die Funktion, sowohl Singles mit 45 als auch mit 33 RPM abzuspielen, was meistens Intermix genannt wird. Dafür ist die Auto-Speed-Unit verantwortlich, die von 33 auf 45 rpm umschaltet, wenn eine Single mit großem Mittelloch eingespannt wird.
Darüber hinaus konnte man 20 kleine LP-Schallplatten, die max. drei Lieder je Seite hatten, für eine sog. "Albumwahl" einsortieren (nicht zu verwechseln mit den reg. 12" LPs). Hier wurden dann immer beide Seiten gleich hintereinander gespielt, auch wenn nur eine gewählt wurde.  Natürlich war der Preis für eine Wahl dann auch teurer, was man entsprechend einstellen konnte. Diese 20 Alben waren in der obersten Leiste in Form von Miniatur-Plattencovern sowie in der Coverablage oberhalb des Titelhalters zu sehen. Die Alben bekamen im Titelhalter und im Plattenmagazin einen besonderen Platz, damit die Wahl korrekt umgesetzt wurde.
Der Name "LPC480" kommt von "Long Play Console" und dass theoretisch, sollten nur solche Alben einsortiert werden, 480 Titel spielbar wären.
Die LPC480 zieht die Singles nicht beim Fahren von rechts nach links heraus, sondern spielt beide Seiten nacheinander beim Fahren von links nach rechts.

LPC480D:
Die Seeburg LPC480D war als sog. Discothèque Musik Center konzipiert. Zur Box selbst gehörten noch zwei Discothèque Zusatzlautsprecher sowie Seeburg Rec-O-Dance Schallplatten. Die Musikbox selbst war mit dem Discothèque Umschalter hinten in der Box ausgestattet. So konnte die Box sowohl in der Standardversion = normale Auswahl der Single und Alben - und als Discothèque verwendet werden = nur noch Auswählen der Rec-O-Dance Tanzplatten. So wurde vermieden, dass "nicht tanzbare" Musik gewählt wurde.
Wurden dennoch normale Singles /Alben gewählt, blieben diese im Tormaten gespeichert und abgespielt, wenn die Discothéque-Option wieder ausgeschaltet wurde.
Seeburg HLPC-1 Discothèque version

Spotlighted Album Award:
Das Lauflicht bleibt hinter einem der LP-Alben stehen. Ein tiefer Klingelton signalisiert das Anhalten dieses Lichts. Das Licht hält ca. 40 Sekunden lang an, und während dieser Zeit darf der Kunde dieses Album für den halben Preis - 25 Cent - abspielen. Ein Fünfzig-Cent-Wert für nur einen Quarter (25 cent).
IMPULSION - der Anreiz des "besonderen Wertes" kommt mit der LP Console 480 mit Seeburgs neuem "Spotlight Album Award".



LPC480
Model LPC480 came with the feature to play both 45 and 33 rpm records which was usually called "Intermix". The auto-speed unit switches the speed from 33 to 45 rpm when a record with large centre hole comes.

Furthermore 20 little LP-records with a max. of three songs per side could be inserted for a so called "album selection" (please note: not 12" records are meant. This feature made that always both sides of a LP-record were played in row even if only one side was selected.
Of course the price for these selections was more expensive which could be adjusted by the operator. These 20 album had been displayed both in the upper trim as miniature LP-covers and above the title strip older where the record covers are.  Within the title strip holder and the magazin these albums got an extra place so these selections were made correctly.
The name "LPC 480" comes from "Long Play Console" and - at least theoretically - if only album records were inserted 480 tunes could be played.
Model LPC480 does not pick up the records when scanning from right to the left but will play both left and right sides while scanning from left to the right.

LPC480D:
The Seeburg LPC480D was designed to operate as a Discothéque Music Center. In conjunction with the jukebox two Discothèque extra speakers and Rec-O-Dance records were set up.
The mode of operation was controlled by a switch located at the rear of the phonograph. When in the "DISCOTHEQUE" position, only Rec-O-Dance records will be played, that is, the playing of Singles and Albums will be suspended and the Album Award feature will not operate during Discothèque presentation. Album and Single selections will be stored in the Tormat Memory Unit; they will be played after the Discothèque switch has been restored to the "NORMAL" position.
Seeburg HLPC-1 Discothèque version

Spotlighted Album Award:
The traversing light will stop and hold behind one of the LP albums. A lower chime denotes the stopping of this light. The light will hold for approx. 40 seconds and during this time, the patron may play this album for one-half the price - 25 cent. A fifty centy value for only a quarter.
IMPULSION - the impelling lure of "special value" comes to LP Console 480 with Seeburg's new Spotlighted Album Award.





EAPU2 - Album Pricing Unit

Seeburg APU2

Seeburg APU2 Seeburg APU2

Seeburg APU2

Seeburg APU2







Stereo Network SN-8: For LPC480D and LPC480DR

Photos courtesy of Bill Butterfield
Seeburg Stereonetwork SN-8

Seeburg Stereonetwork SN-8





HLPC (1963-66)

Seeburg HLPC

Seeburg HLPC-1
Specifications and cabinet cabling diagram





Technische Daten - Specifications
  LPC480 HLPC
Wahlen / Selections 160 160
Lampen / Lamps Cabinet: 2x TL 30W/36"   |   Record indicator: 2x GE #19
Credit: 2x GE #55   |   Counter: GE #57 - alternatively GE #55
Album: 15 x #93
Album instruction: 1x GE #93 + # 53 + # 257
./.
Verstärker / Amplifier TSA-1 TSA-1
Netzteil / Power supply TCC1: 2x 2050, 6X4, 2x 0A2, 2x 12AX7 TCC1: 2x 2050, 6X4, 2x 0A2, 2x 12AX7
Stepper RSCU5, RSCU5-H5 RSCU5, RSCU5-H5
Mechanismus / Mechanism 133S3 133S2
Electrical Selector TES 169-56 TES 169-56
Tormat 160TM2 160TM2
Kreditgerät / Credit unit APU2; EAPU2-H5 (Germany) ./.
Auto-Speed-Unit 45TASU1: Transistor 2x GC433 45TASU1: Transistor 2x GC433
Lautsprecher / Speaker Low: 2x 12" 16 Ohm, # 488812
Mid: 2x 6x9", 16 Ohm # 488814
High: 2x 5" 16 Ohm Cadmium by Utah, # 488811
LPC480, LPC480R: Stereo Network: SN7
LPC480D, LPC480DR: Stereo Network SN8
./.
Tonabnehmer / Cartridge Seeburg first stereo cartridge
Sicherungen / Fuses Tormat: 15A   |   Amplifier: 800 mA   |   Mechanism: 5 A
Stepper: 3,2A   |   APU 500 mA and 1.6A
115V Power Junction: 6.25A; 235V Power Junction: 3.2A
Tormat: 15A   |   Amplifier: 800 mA   |   Mechanism: 5 A
Stepper: 3,2A   |   APU 500 mA and 1.6A
115V Power Junction: 6.25A; 235V Power Junction: 3.2A
Schlüssel / Key F-278
Abmessungen / Size 52-1/4 x 40-1/2 x 24-1/2"; 385 lbs
Zubehör / Accessories Extra speaker DDS1, DDS2, DWS1, DWS2
Wallbox Consolette SC1; PVCR 2
, PVCR 3;
Discothèque Dance Kit DDC1K
45 rpm Discothek records in different label colours (classifications)
Extra speaker DDS1, DDS2, DWS1, DWS2
Wallbox Consolette SC1; PVCR 2
, PVCR 3;
Discothèque Dance Kit DDC1K
45 rpm Discothek records in different label colours (classifications)
Besonderheiten / Special Album Play Bonus Feature




Seeburg Discotek Records

Seeburg Discotheque

Seeburg Discotheque
Seeburg Discotheque Seeburg Discotheque

Seeburg Discotheque

Medium blue -  Adult Music Series - numbers in 1000's
Pale blue - Discotheque Series - numbers in 1000's
Red - Discoteen Series - numbers in 3000's
Orange - Rhythm Series - numbers in 5000's
Dark green - C & W Series - numbers in 7000's

There must be other label colors for 2000's, 4000's and 6000's probably.

Pictures and information: Bill Butterfield





Die Angaben haben keinen Anspruch auf Vollständigkeit oder Richtigkeit.
Bei den (importierten) Boxen können im Laufe der Jahre durchaus Veränderungen vorgenommen worden sein. Copyright.
