Bilder AMI im Archiv von Jukebox-World

AMI G-40 (1955)   |   G-80 (1955)  |   G-120 (1955)  |   G-200 (1956)

Copyright

Lizenz: National Instruments Pty. Ltd., Australien

AMI-History-Book: The "G" was available in the following colors:
Delft Blue, Cherry Red, Emberred Charcoal, Chartreuse Green, Bright Sand, Canary Yellow, Atoll Coral, and Night-Sky Black

Erste Vorstellung:
Modelle G40, G80 und G120: 25.9.1955
Modell G200: Mai 1956


  Also produced in license by National Instruments Pty. Ltd., Australia

AMI-History-Book: The "G" was available in the following colors:
Delft Blue, Cherry Red, Emberred Charcoal, Chartreuse Green, Bright Sand, Canary Yellow, Atoll Coral, and Night-Sky Black

First presentation:
Models G40, G80 and G120 on Sep 25, 1955
Model G200: May 1956


AMI G-40 - 1955

AMI G 40



Technische Daten - Specifications G-40

Wahlen / Selections

40 – 78 RPM; Mechanism could be converted to 45 rpm

Lampen / Lamps

Top Light: 20W/24"/T12    |   Grill: 15W/18"/T8     |     Coin chute: 7C7W frosted 7W     |     Credit: GE #47

Verstärker / Amplifier

R-144 (mono): Valves 12AX7, 12AU7, 2x 6L6, 5U4

Netzteil / Power supply

L 519

Kreditgerät / Credit unit



Lautsprecher / Speaker



Mechanismus / Mechanism

R-220

Tonabnehmer / Cartridge

Up to serial number 300186: GE RPX-040 / GE RPX-046       |     Serial number 300187 and up: GE RPJ-RPX

Sicherungen / Fuses

Amplifier: 1x 2A quick blo   |   Junction box: 8A quick blo, 2x 800 mA slo blo

Schlüssel / Key

50A-1

Abmessungen / Size

H 61-1/4" x W 32-3/8" x D 26-5/16"; 277 lbs

Zubehör / Accessories

Wallbox W40   |   Stepper S40   |   Remote control H-338   |   Extra Speaker EX 100, EX-200, EX-300

Besonderheiten / Features

Cabinet available in eight colour versions: Delft Blue, Cherry Red, Emberred Charcoal, Chartreuse Green, Bright Sand, Canary Yellow, Atoll Coral, and Night-Sky Black



AMI G 80 - 1955

Bilder: Adi Gavoldi
AMI G 80 AMI G 80

AMI G 80





Australian version G-80 produced by National Instruments Pty. Ltd., Australia

Photos by courtesy of Ken Reed
AMI National Instruments G 80

AMI National Instruments G 80

Amplifier RA-145:
This was made for Australian mains voltage, the selector at front left can be set to either 230, 240 or 250v AC. The National AMI Logo can be seen at right. The Phono input socket was not an RCA plug but a plug type I have not seen before - it is much the same size as the base of a bayonet fitting #44 pinball bulb and connects to the amplifier socket exactly the same way as the #44 bulb would go into a socket.

AMI National Instruments G 80

AMI National Instruments G 80 RA-145

AMI National Instruments G 80 RA-145

AMI National Instruments G 80 RA-145

AMI National Instruments G 80

More information about AUS electrical devices





Technische Daten - Specifications G-80

Wahlen / Selections

80 – 45 rpm

Lampen / Lamps

Top Light: 20W/24"/T12    |   Grill: 15W/18"/T8     |     Coin chute: 7C7W frosted 7W     |     Credit: GE #47

Verstärker / Amplifier

USA: R-145 (mono)
12AX7; 2x 12AU7; 2x 6L6; 5U4; Pot: 35 KΩ

Australia: RA-145 (mono) - made for 230 - 250 VAC
12AX7; 2x 12AU7; 2x 6L6; 5U4; Pot: 35 KΩ
Lautstärkeregler / Volume Control H338
Netzteil / Power supply

L 519

Kreditgerät / Credit unit



Lautsprecher / Speaker



Mechanismus / Mechanism

700

Tonabnehmer / Cartridge

GE RPJ-RPX

Sicherungen / Fuses

Amplifier: 1x 2A quick blo   |   Junction box: 8A quick blo, 2x 800 mA slo blo

Schlüssel / Key

50A-1

Abmessungen / Size

H 61-1/4" x W 32-3/8" x D 26-5/16"; 306 lbs

Zubehör / Accessories

Wallbox W120   |   Stepper S80   |   Remote control H-338
Extra Speaker EX 100, EX-200, EX-300

Besonderheiten / Features

#326825 and up: With amplifier R-145 with changes regarding the AVC H-486 - compare Service Bulletin #134, dated Nov. 20 1956
Available in eight colour versions: Delft Blue, Cherry Red, Emberred Charcoal, Chartreuse Green, Bright Sand, Canary Yellow, Atoll Coral, and Night-Sky Black



G 120 - 1955

Bilder: Adi Gavoldi
AMI G 120 AMI G 120
Picture: Thor Haugen

AMI G 120



Technische Daten - Specifications G-120

Wahlen / Selections

120 – 45 rpm

Lampen / Lamps

Top Light: 25W/33"/T12     |     Grill: 15W/18"/T8     |     Coin chute: 7C7W frosted 7W     |     Credit: GE #47

Verstärker / Amplifier

R-145 (mono): 12AX7; 2x 12AU7; 2x 6L6; 5U4; Pot: 35 KΩ

Netzteil / Power supply

L 519

Kreditgerät / Credit unit



Lautsprecher / Speaker



Mechanismus / Mechanism

800

Tonabnehmer / Cartridge

GE RPJ-RPX

Sicherungen / Fuses

Amplifier: 1x 2A quick blo   |   Junction box: 8A quick blo, 2x 800 mA slo blo

Schlüssel / Key

50A-1

Abmessungen / Size

H 62-1/2" x W 36-9/816 x D 26-5/16"; 330 lbs

Zubehör / Accessories


Wallbox W120   |   Stepper S120   |   Remote control H-338
Extra Speaker EX 100, EX-200, EX-300

Besonderheiten / Features


Available in eight colour versions: Delft Blue, Cherry Red, Emberred Charcoal, Chartreuse Green, Bright Sand, Canary Yellow, Atoll Coral, and Night-Sky Black



G 200 - 1956

Vorgestellt Mai 1956
Erste AMI mit Plattenkarussell
in Lizenz gebaut durch
National Instruments Pty. Ltd., Australien

Introduced in May 1956
First AMI with a rotating record magazin.
Also produced in license by
National Instruments Pty. Ltd., Australia

AMI G200 Musikbox Jukebox G200





Technische Daten - Specifications
Wahlen / Selections 200 – 45 rpm
Lampen / Lamps Credit: 2x GE #47     |     Coin chute: 7C7W frosted 7W     |     cabinet: 20W/T12/24"; 4W/T5/6"; 15W/T8/18"
Verstärker / Amplifier R-145 (mono): 12AX7; 2x 12AU7; 2x 6L6; 5U4; Pot: 35 KΩ
Netzteil / Power supply L 1249
Kreditgerät / Credit unit
Lautsprecher / Speaker
Mechanismus / Mechanism 900
Tonabnehmer / Cartridge GE VRII
Sicherungen / Fuses Amplifier: 1x 2A     |     Junction box: 8A (fl.), 1A, 1x 2A, 0.8A
Schlüssel / Key RI-303
Abmessungen / Size
Zubehör / Accessories Wallbox WQ200 / WQ120; remote control H-338
Extra Speaker EX 100, EX-200; EX-300; Automix-Kit 45-33: R-2047A;
Designer Mechanism H.H. Vanderzee - patent 292463 - filed 1954 - "Record Selecting Mechanism"

Besonderheiten / Features

Available in eight colour versions: Delft Blue, Cherry Red, Emberred Charcoal, Chartreuse Green, Bright Sand, Canary Yellow, Atoll Coral, and Night-Sky Black
Stepper built-in (pulse generator)

#350450 and up

With four credit magnets in the credit unit. Compare Service Bulletin #120, dated April 20, 1956.

#352325 and up

With an add. 2A fuse (slo-blo) which has been installed in junction box to protect transformer from damage in cases where the rectifier should become internally shorted.

#354771 and up

With new plastic cash box (L-1271) to replace H-1242.

#356400 and up

With amplifier R-145 with changes regarding the AVC H-486. Compare Service Bulletin #134, dated Nov. 20 1956

#357168 and up

With pulse converter employing a gear drive between the selector drive motor and the sprag wheel.
